Pulsar – PTX Series – PTX3067R Gen 2

Pulsar – PTX Series – PTX3067R Gen 2

Pulsar – PTX Series – PTX3067R Gen 2

Pulsar PTX3076R Gen 2

Please note, T51R housing option requires an extra 7 days handling time
Recommended displacement 1.8 to 3.0 litres with power outputs up to 700hp possible.
Dual Ceramic Ball Bearing System
9 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
Inconel 713c 10 Blade Turbine Wheel
Gen2 Cover Integrated with the Speed Sensor Port
0.83 A/R dual v-band turbine housing, T3 0.63, 0.82 V-Band outlet turbine housing In option
V-Band Flange kit(s) for the exhaust housing included
Max Air Flow rate: 65 lb/min, rated @ 750 FWHP
Supplied with manifold to turbine gasket and 5 bolt gasket (where applicable). Oil feed restrictor supplied (where applicable).
Wastegate actuator supplied on internally gated units with compressor housing.
SPEC

Compressor Wheel: 58*76mm
Turbine Wheel: 60*55mm
Compressor Inlet: 4? Hose
Compressor Outlet: 2? Hose
Turbine Inlet: T3, T4 or 2? V-Band
Turbine Outlet: 3? V-Band(3.55?OD)
Oil Feed: -4 AN Oil Restrictor connection.
Oil Drain: Std T3 Flange
Water In/Outlet: M14*1.5
It’s strongly recommended to run water cooling to aid reliability.
